Dynemech Machinery Raiser Damping Block Mounts Series -DRC1 U

Dynemech Machinery Raiser Damping Blocks Series DRC-u: are suitable for machines having tapped hole in the base. The bolt rests over the dimple provided on the top face of the mount. Dimple size is provided as per the bolt diameter in the machine base. Levelling is done by turning the bolt which lifts the cover plate along with the machine. Available both in 150 & 100 mm height. Compressors, Tool Room Machines, Plastic injection Moulding Machines, Pressure Die Casting Machines, Shaper, Printing and Textile Machines etc.

Model: DRC1-u

Load kg/pc: 350 Kg/pc to 2200 Kg/pc M12x1.75x100 To M20x2.5X150mm

d (mm): (98 to 235) mm

Dia D (mm): (109 to 270)mm

Height: (100/150 to 110/160) mm

Adj. (mm): (8 to 12) mm

Hardness: (90 to 92) mm

Material: Cast Iron

Colour: Green

Surface Finishing: Painted

Temperature: (-20 to +70°C)

Weight: 22 Kg Delivery Time: 1-2 Days No. of Boxes: 1

Box Dimension: 13"X8"X7" Production Capacity: 50 Pcs/Per Day

Note- GST and Freight Charges are not included.
