Dynemech Anti Vibration Table for Duramax Cmm, P-69

1. Granite base of size : L 800 X B 950 X T 100 mm
2. Wrap Around Construction
3. 72 × 72 mm HR tubular structure
4. 4 No’s DLP4 (AV disc with adjustable screws) at Ground Level
5. 13 no’s AV pad between structure and granite base
6. 6 no’s – 4” wheel
7. Cable manager in R.H. Side and rear side, power strip in rear side
8. Drawing pouch; controller, CPU and UPS inside structure
9. Front double door with handles and lock
10. Powder coat color as per customer specification
11. Front swing arm in pivoted joint assembly with horizontal and vertical supported profile to hold monitor, keyboard and mouse. Can be mounted on LH or RH side (newly introduced!)
12. Overall dimensions: L 830 X B 980 X H 750 mm
13. Weight:
14. Execution in wooden box

[Note: We will provide the dimensions]

Note- GST and Freight Charges are not included.
