Dynemech Granite Anti Vibrating Table for Profile Projector , P-86-01-A

1. Granite size L 600 x B 900 x T 50 mm over steel structure
2. 60 x 60 mm Square Tubular Structure with cross member
3. Wrap around construction
4. 4 Nos. 4’’ wheels
5. 4 Nos. DLP4 AV discs at floor level
6. 9 Nos. 65 x 65 mm AV Pads between Granite and structure
7. Front double door with handles and lock
8. Drawing pouch, leveling ball, spanner 24/27
9. Power Strip in Rear
10. Drawing Pouch LH Side
11. Powder Coat, structure RAL 9002, side sheets and doors – graphite gray
12. Instrument sticker
13. Overall dimensions: L 620 X B 920 X H 730 (over granite base) mm
14. Weight: kg
15. Execution in wooden box

Note- GST and Freight Charges are not included.
