Dynemech Machinery Raiser Damping Block Mount Series - DRS1 65 U

DRS series mounts are available in different heights as per the required ground clearance. The options of threading and dimple are available for levelling the machine. The vibration reduction is done using vibration isolation sheet of tuned natural frequency under the base of this mount.

Model: DRS1-65-u

Load Capacity(Kg/pc): (1160 to 7200)Kg/pc

Height H(mm): (50 to 65)mm

A(mm): (150 to 150)mm

Dimple: 28 to 32

Natural Frequency: 30 to 45

Co-effcient of Friction: 0.7 to 0.6

Thickness: (50 to 65)mm

Hardness: (90 to 92)mm

Material: Cast Iron

Colour: Green

Surface Finishing: Painted Temperature: (-20 to +70°C)

Weight: 20 Kgs Delivery Time: 1-2 Days No. of Boxes: 1

Box Dimension: 13"X8"X7" Production Capacity: 50 Pcs/Per Day

Note- GST and Freight Charges are not included.
