Dynemech Shockproof Self Leveling Feet Heavy Duty Leveling Screw Leg with Non-Skid Base Series DLMS1-u

Dynemech DLMS Series Antivibration Mounts, developed in steel and stainless steel respectively are simple and effective vibration dampers for machines with respective holes in the base. These mounts offer low frequency attenuation, stable machine levelling and vibration reduction. The flexible levelling screw accommodates uneven/sloped surface up to 5 degree. DLMS Series find application where corrosion resistant materials for hygienic, climatic and environmental reasons are required like in pharmaceutical, food and beverages processing and packaging units, medical equipment manufacturing and chemical processing industries.

Size :Dia-59(mm), Height-21(mm)

Load Capacity (Kg.):150 Kg/pc

Bolt Size:M16x2.0x100mm                Natural Frequency (Hz):18

Coeff. of Friction:0.9

Working Temp Range °C:-16 to 90

Weight ( Kg.):14 Kg.

Material:Rubber+Cust Iron+Mild steel

Colour:Green & Dark Grey

Note- GST and Freight Charges are not included.
