| Business Type | Manufacturer, Exporter, Supplier, Trader |
| Load | 96 Kg |
| Type | Spring Isolator, RCD RT SP2 |
| Features | Dynemech Is Providing Anti Vibration Solutions To The Indian Industry For The Last 10 Years. We Are |
| Click to view more | |
Product Details
Certification
ISO 9001;2008 Certified
Color
Blue And Dark Grey
Application
Industrial
Material
IS2062
Country of Origin
India
Brand Name
Dynemech
Size
Load(Kg):82-900 , Free Height H (mm):161.5
Load Capacity
96
Warranty
1
Port
Haryana
Payment Terms
Western Union
Packaging Details
Wooden and Corrugated Boxes As Per Customer Requirement
Dynemech Spring Isolator
Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine. Viscous Damping is an important feature of an isolation system. In most cases viscous damping is required to limit excessive movement which could occur as a machine operates at a speed near to, or coinciding with the resonant frequencies of the system. Generally this problem arises during slow run up and run down of rotating machines and during impact at each stroke in presses and hammers.
Model:RCD-J2-RT-SP2 Load(Kg):82-900
Free Height H (mm):161.5 Bolt Size: M16
Top Plate AXB(mm):235x235 Bottom Plate CXD(mm):235x235 CC(mm):205
Natural Frequency Range(Hz):3.5-11
Looking for "Dynemech Round Spring Vibration Isolators with Damping Series RCD-RT-SP2" ?
