Dynemech Spring Isolators Series RDD-P5

Link Copied

5,600.00 / Piece

4 Pieces (MOQ)

Edit

Business Type	Manufacturer, Exporter, Supplier, Trader
Color	Black
Material	Cast Iron
Type	Spring Isolator
Click to view more

Product Details

Country of Origin

India

Application

Industrial Use, Vibration Isolation For Machinery

Brand Name

Dynemech

Series

RDD P5

Port

Haryana

Payment Terms

Western Union

Delivery Time

5-7 Days

Packaging Details

Wooden and Corrugated Boxes As Per Customer Requirement.

Dynemech Spring Isolators provides high vibration isolation to plant and machinery and HVAC equipments.These isolators are compact and economical.

Size: HO(mm):89mm HI(mm):98mm Load (Kg):1000Kg/pc To 3600 Kg/pc

Bolt Size:M16X2.0X150mm

Top Plate (AxB)(mm):246X222(mm)

Bottom Plate (CxD)(mm):291X196 (mm)

CC(mm):261mm

Natural Frequency Range(Hz):5.0-10.0Hz

Weight Of 04 Nos ( Kg.):65 Kgs

Box Dimension:12"x12"x10

Number Of Box-02

Material: Low Carbon Steel & Rubber

Colour: Green & Grey

Note- GST and Freight Charges are not included.
