GST NO. : 06AABCD4754E1ZX
| Business Type | Manufacturer, Exporter, Supplier, Trader |
| Brand Name | Dynemech |
| Color | Black,Grey,Green,Grey And Black |
| Size | 500x500x15mm |
| Click to view more | |
Product Details
Type
Anti Vibration Pad,Insulation Plate
Thickness
15mm
Country of Origin
India
Series
DM
Material Available
Nitrile Rubber, Cork, Synthetic Fibre
Max Withstanding Temperature
-20 To +70
Coeff. Of Friction
0.7
Natural Frequency
30-50 Hz
Warranty
1
Material
Rubber
Load Capacity
5-10 Kg/Sq Cm
Port
Haryana
Payment Terms
Western Union
Delivery Time
2-3 Days
Packaging Details
Wooden and Corrugated Boxes As Per Customer Requirement
Dynemech Anti-vibration Dm Insulation Plate is made from high grade synthetic composite material. This sheet is resistant to water,
oils, lubricating oils, fuels, etc. used in shop floor. This sheet has defined stress value and can be placed directly under the machine
as per the weight of the machine and no. of mounting positions. This sheet will not deform plastically, if the weight of machine does
not exceed maximum load value of this insulation plate..
Lathe Machines, Milling Machines, Grinding Machines, Machining Centres, Turning Centres etc.
Note- GST and Freight Charges are not included.
Looking for "Dynemech Insulation Plate, Isolation Pads , Series DM" ?
pieceS
